Truck Mounted Type 400L Road Crack Sealer
1.Products Introduction
Truck mounted type Crack sealing machine is a road maintenance machine for repairing the pavement cracks, which is used for heating and pouring the sealant evenly into the treated cracks to achieve the waterproof purpose. It’s composed of chassis, power, driving motors, control system, heating system and pumping system. It’s used with router, vacuum cleaner or hot air lance. It applies to the residential, municipal, highway, freeway, airport and other pavement.
2. Specification
1. Reliable Loncin gasoline engine-generator; Electric driven stirring and pumping.
2. Riello burner, multi-layer melter with agitator, heat transfer oil heating, uniform and fast.
3. Control panel controls heating, stirring and pumping; Maintenance-free submerged pump；Sealing wand controls pump flow, backflow available; 360 degrees rotating electric heated hose.
3.Parameter
| Item | Specifications |
| N.W | 1000kg |
| Engine | 5.0kw gasoline generator |
| Hot kettle capacity | 400L |
| Heat oil capacity | 50L |
| Oil capacity | 30L |
| Diesel burner | Italian Riello diesel burner; Burning Power: 50000kcal |
| Burner control | Computer automatic control |
| Temperature control system | LED digital liquid crystal display mode |
| Material transmitting mechanism | Built-in material pump: the infinite speed regulation control |
| sealing material heating time | about 40 mins |
| Output Hose | 6M electric heating hose, could rotate 360°, equipped with spout insulated chamber |
| Vehicle Damping System | Lever compressional moded shock absorbers |
| Insulated gun spout | We have got heat preservation box design of the gun spout, solve the problems that there is no place to put the gun at temporary shutdown process |
| Accessories | Built-in tool box and on-vehicle tools |
4. Company Introduction
Founded in 2002, Hefei Huayang Construction Machinery Co., Ltd is located in the cultural and historical city - Hefei, Anhui Province, China. After more than 20 years of development, the company has developed into a full line of special vehicle, road maintenance equipment manufacturer with fully integrated design, products development, manufacturing and distribution capabilities for both domestic and export markets.
We possess the independent intellectual property rights on LULAIRUIDE road maintenance equipment, including road crack sealing machines, asphalt crack router, anti collision truck, truck mounted hedge trimmer, road maintenance truck and etc. We adopt methods of serialization, standardization and modularization during our manufacturing process. Besides, we integrate advanced design concepts with actual customer demand. At the meantime, we gather customer suggestions and improve our products constantly to keep always standing at the forefront of industry technology development. We are always committed to provide our customers with professional, timely and considerate after-sales service.
|
|
Truck Mounted Type 400L Road Crack Sealer Images
|
